Annovi Reverberi AR1064S diaphragm pump Honda GX630 108.5 lpm 50 bar (725 psi) 500 m head
Couldn't load pickup availability
Annovi Reverberi AR1064S GCI engine driven diaphragm pump
Honda GX 630 engine electric start
108.5 lpm
50 bar (725 psi)
500 m head
Excludes battery, leads and fuel tank
Semi-hydraulic four-diaphragm pump, for use on sprayers for high pressure pesticide spraying in orchards and vineyards
Parts in contact with pumped liquids in anodized aluminium, and AISI 303/304
4 x longlife BlueFlex diaphragms
Seals in NBR
Die-cast casing with oil-immersed mechanism and clear plastic tank for visual level checking
Fitted with air-hydraulic damper for smoother operation and less hammer effect in the delivery circuit
Remote level monitoring sensor on request
Remote oil tank installation kit available on request
Oil drainage stopper
Pistons with ring for a more efficient oil cushion system to protect the diaphragm
New-design diaphragm cut-out system to prevent contact tearing even in heavy-duty operating conditions
Spherical sector profile valves for lower flow resistance and improved volumetric efficiency
Mass-produced safety valve and cardan protection
Metal fasteners with galvanised finish
Includes VDR50 I control valve and pressure gauge
