Johnson F4B-19 flexible impeller pump 12/24v DC options 1/2 inch NPT(F) 0.6 bar 48 lpm
Couldn't load pickup availability
Johnson F4B-19 flexible impeller pump 12/24v DC options 1/2 inch NPT(F)
0.6 bar 48 lpm
With their high level of flexibility, these pumps are ideally suited for use in boats as bilge and deck-wash pumps, freshwater pumps, refueling pumps for oil and diesel
These pumps may be combined with a vacuum switch for automatic operation.
Heavy duty motor to provide long service life even under heavy use; motor has additionally a built-in thermal overload for added protection
Continuous operation capable up to max. 0.6 bar head pressure
Self-priming up to 4 m under perfect conditions, maximum head should not exceed 6 m
Output up to 48 lpm at free flow; approx. 41 lpm at 3 m head
With brass pump head and oil resistant nitrile impeller
Shaft seal : Lip seal
Connections: 25 mm (1 inch) hose inner diameter directly to inlet / outlet connection or via R1/2" female thread for corresponding fittings (not included)
Amperage 18,3A; fuse size 25A
Dimensions: Height 9,0 cm / Width 12 cm / Length 20,8 cm
