Heavy-duty positive-displacement rotary gear pump for transferring oils, fuels and compatible high-viscosity liquids.
Performance
Rated speed
1440 rpm
Maximum pressure
10 bar (145 psi)
Maximum viscosity
Up to 100,000 SSU
Maximum liquid temperature
Up to 200°C
Construction
Pump type
Positive-displacement rotary twin-gear pump
Pump body
Heavy-duty cast iron
Connections
BSP(F) threaded flange ports included
Gear design
Refined double-helical herringbone gears
Shaft
Hardened, precision-ground shaft
Pressure protection
Integral pressure-relief valve
Construction
Three-piece design for easy cleaning and maintenance
Mounting
Heavy-duty foot-mounting base
Key features
✓ Continuous-duty rated
✓ Integral pressure-relief valve
✓ Handles high-viscosity liquids
✓ Threaded flange ports included
✓ Herringbone gears eliminate side thrust
✓ Floating gears distribute load uniformly
✓ Hardened, precision-ground shaft
✓ Easy cleaning and maintenance
Typical applications
Oils and fuels
Gear oil, hydraulic oil, animal oil, fish oil, vegetable oil, furnace oil, petroleum products, naphtha and RFO
High-viscosity products
Bitumen, asphalt, tar, wax, silicate and other compatible viscous liquids
Food products
Honey, molasses and starch
